Powerwerx - Red/Black Zip Cord (Gauge 6) By the Foot

$3.63
Availability: Translation missing: en.general.icons.icon_check_circle icon 69 in stock, ready to be shipped

Red/Black Zip Cord is a low voltage DC power cable. Also called zip wire and bonded wire, the cables pull apart for quick separation. Easy to identify polarity for DC applications. Excellent for Amateur Radio, Automotive/Stereo, Robotics and R/C.

Conductor: Extra flexible soft bare copper stranding for maximum flexibility and conductivity

Insulation: Automotive grade "GPT" PVC insulation which is oil & gas resistant

Temperature Range: -40°C to +80°C (-40°F to +176°F)

Compliances: Designed to meet UL VW-1 Vertical Wire Flame Test, RoHS Compliant

Voltage Rating: 300 VAC

Gauge (AWG) Number of Strands Gauge of Strands (AWG) Finished Wire Diameter
Inch mm
2 260 26 0.45 x 0.97 11.43 x 24.64
4 137 25 0.43 x 0.89 10.92 x 22.61
6 262 30 0.32 x 0.69 8.13 x 17.53
8 165 30 0.24 x 0.48 6.10 x 12.19
10 105 30 0.19 x 0.41 4.83 x 10.42
12 67 30 0.16 x 0.33 4.06 x 8.38
14 42 30 0.14 x 0.30 3.56 x 7.62
16 27 30 0.12 x 0.24 3.04 x 6.10
18 17 30 0.09 x 0.19 2.29 x 4.83
20 10 30 0.08 x 0.17 2.03 x 4.32
22 7 30 0.07 x 0.16 1.78 x 4.06
24 7 32 0.06 x 0.13 1.52 x 3.30
